►Suspension records

X/Y are named with the NEW convention.

ITMX

OSEM

S/N

Max out

Max/2


Satellite Box #???

UL

284

1.97

0.985

UR

306

1.71

0.855

LR

264

1.47

0.735

LL

219

1.55

0.775

SD

261

1.67

0.835

ITMY

OSEM

S/N

Max out

Max/2


Satellite Box #105

UL

220

1.788

0.894

UR

289

1.656

0.828

LR

303

1.670

0.835

LL

207

1.903

0.952

SD

277

2.002

1.001

ETMX

OSEM

S/N

Max out

Max/2

Satellite Box #???

UL

526

1.47

0.735

UR

567

1.36

0.68

LR

513

1.60

0.80

LL

511

1.76

0.88

SD

590

0.108(?)

-

ETMY

OSEM

S/N

Max out

Max/2

Satellite Box #???

UL

502

1.7

0.85

UR

568

1.631

0.8155

LR

226

2.105

1.0525

LL

205

1.582

0.791

SD

552

1.490

0.745

PRM

OSEM

S/N

Max out

Max/2


Satellite Box #???

UL

516

1.748

0.874

Short OSEMs

UR

520

1.695

0.848

LR

504

1.934

0.967

LL

511

2.076

1.038

SD

500

9.21 1.680

4.605

SRM

OSEM

S/N

Max out

Max/2


Satellite Box #???

UL

522

1.744

0.872

Short OSEMs

UR

513

1.773

0.887

LR

515

1.636

0.818

LL

519

2.071

1.036

SD

502

1.758

0.879

BS

OSEM

S/N

Max out

Max/2

Satellite Box #???

UL

-

1.50

0.75

UR

-

1.57

0.785

LR

-

1.57

0.785

LL

-

1.38

0.69

SD

-

1.57

0.785

MC1

OSEM

S/N

Max out

Max/2

Satellite Box #???

UL

-

1.3

0.650

UR

-

1.4

0.700

LR

-

1.45

0.725

LL

-

1.56

0.780

SD

-

1.67

0.835

MC2

OSEM

S/N

Max out

Max/2

Satellite Box #???

UL

-

-

-

UR

-

-

-

LR

-

-

-

LL

-

-

-

SD

-

-

-

MC3

OSEM

S/N

Max out

Max/2

Satellite Box #???

UL

-

1.37

0.685

UR

-

1.71

0.855

LR

-

1.77

0.885

LL

-

1.56

0.780

SD

-

1.59

0.795
